產品說明
|
袋長范圍
|
70-250 mm（可調）
|
|
袋寬范圍
|
50-200 mm（可調）
|
|
包裝物厚度
|
0.2-30mm
|
|
包裝速度
|
10-80袋/分（按照包裝列數不同）
|
|
包材最大寬度
|
1012 mm
|
|
真空泵功率
|
2.2KW
|
|
電源
|
380V 50Hz
|
|
總功率
|
6.5Kw
|
|
機器重量
|
1800 Kg
|
|
機器尺寸
|
6300mm×1000mm×1600mm(長×寬×高 ）
|
|
真空度
|
≤200Pa
|
適用范圍：
Scope of application:
本機適用于熟食品、鹵制食品（雞翅、鳳爪、五香干，牛肉、魷魚等）、榨菜、炒貨類、干貨類。加料、制袋、封口、裁切全自動完成，并帶有自動抽真空、計數；配碳帶日期打印；自動控溫，自動光電跟蹤，變頻無極調速。
This machine is suitable for cooked food, spiced food (chicken wings, chicken, spicy dry, beef, squid etc.), mustard, roasted seeds and nuts, dry cargo class. Feeding, bag making, sealing, cutting is finished automatically, and with automatic vacuum pumping, count; with ribbon date printing; automatic temperature control, automatic photoelectric tracking, frequency conversion stepless speed regulation.
功能特點：
Function characteristics:
1.性能先進.在真空包裝機基礎上制袋和包裝一步到位。
2.自動化程度高。本機從卷膜分切打碼反轉、充填裝料、縱封縱切、切易撕口、橫封橫切、直至成品袋輸出能連續一次性完成。
3.次用高精度體滾壓式熱封滾輪作為縱封模具，連續牽行滾壓，確保封口致密嚴實，袋形平整，精致美觀。
4.調整快捷方便。不需要更換模具就可以進行袋長無級調整。且縱封、充填料、打批號、橫封橫切等執行機構均可通過人機界面進行調整。
5.整機采用進口PLC控制，各執行機構全部采用伺服電機驅動，使各執行機構均能精確自動同步定位。
6.采用光電跟蹤系統，保證了包裝袋雙面圖案對版。
1 advanced performance. Making based on vacuum packaging machine and packaging in one step.
2 high degree of automation. This machine from the film cutting code inversion, filling loading, vertical slitting, cutting easy tearing notches, transverse sealing cutting, until the finished bag output can continuously complete.
3 high precision body rolling type heat sealing wheel as longitudinal sealing mould, continuous traction for rolling, to ensure the sealing tightly, a smooth, delicate and beautiful.
4 convenient and quick adjustment. Does not require the replacement of mold can be stepless adjustment bag length. And the vertical sealing, filling, batch number, transverse sealing cutting actuators can be adjusted through the man-machine interface.
5 the machine adopts imported PLC control, the implementation mechanism adopts the servo motor drive, so that the implementing agencies can accurate positioning automatic synchronization.
6 photoelectric tracking system is adopted to ensure the packing bag, double side pattern on version.
|
